Downloads

Brochures

Abrasive media & Service+

Precision instruments for industrial applications

 Download

KOTAR

KOTAR combines the advantages of an LC blasting agent with the performance of an HC material

 Download

Peenox Perform+

Lasts longer, saves costs - Peenox® Perform+ is the steel wire grain of the future.

 Download

Data sheets

Peenox® CS (SAE AMS)

Steel wire grain

Hardness: min. SAE AMS 2431/3: 45 – 52 HRC (450 – 550 HV1)
Size: von 0.30 (AWC 12: 0.012") – 2.40 mm (AWC 96: 0.096")
Shape: round
Application: Shaping and Hardening

Data sheet (PDF)

Peenox® CS (as cut)

Steel wire grain

Hardness: min. 580 HV1 (54 HRC)
Size: von 0.33 – 1.23 mm
Shape: Cylindrical
Application: Shaping, Hardening and Cleaning



Peenox® Perform+ (VDFI)

Steel wire grain

Hardness: min. HV 640: 610 – 670 HV1 (56 – 59 HRC)
Size: von 0.30 – 1.20 mm
Shape: round
Application: Shaping and Hardening

Data sheet (PDF)

Peenox® Perform+ (SAE AMS)

Steel wire grain

Hardness: min. SAE AMS 2431/3: 45 – 52 HRC (450 – 550 HV1)
Size: von 0.30 (AWC 12: 0.012") – 1.60 mm (AWC 62: 0.062")
Shape: round
Application: Shaping and Hardening

Data sheet (PDF)

Peenox® Perform+ (as cut)

Steel wire grain

Hardness: min. 580 HV1 (54 HRC)
Size: von 0.33 – 1.23 mm
Shape: cylindrical
Application: Shaping, Hardening and Cleaning

Blastex® CS

Steel cut wire shot

Hardness: min. 400 – 550 HV1 (40 – 55 HRC)
Size: von 0.40 – 2.60 mm
Shape: cylindrical
Application: Deburring, Rust removal, Coating removal, Descaling, Cleaning and Cleaning

Data sheet (PDF)

Peenox® CS (nach VDFI)

Steel wire grain

Hardness: 610 – 670 HV1 (56 – 59 HRC)
Size: von 0.30 – 1.20 mm
Shape: gerandet
Application: Shaping/ Hardening

Data sheet (PDF)

Blastex® ST

Stainless steel cut wire shot

Hardness: min. 400 – 550 HV1 (41 – 52 HRC)
Size: von 0.30 – 2.60 mm
Shape: cylindrical
Application: Deburring, Rust removal, Coating removal, Descaling, Cleaning, Cleaning and Structuring

Data sheet (PDF)

Peenox® ST (as cut)

Stainless steel cut wire shot

Hardness: min. 400 HV1 (41 HRC)
Size: von 0.33 – 1.23 mm
Shape: cylindrical
Application: Shaping, Hardening and Cleaning



Peenox® ST

Stainless steel cut wire shot

Hardness: min. 45 HRC (450 HV1)
Size: von 0.30 (AWC 12: 0.012") – 2.40 mm (AWC 96: 0.096")
Shape: round
Application: Shaping and Hardening

Data sheet (PDF)

Chilled iron grit

Cast abrasives

Hardness: Min. 64 HRC (min. 800 HV1)
Size: von 0.10 (G 05) – 2.80 mm (G 80)
Shape: angular
Application: Rust removal, Coating removal, Sweeping, Roughening, Matt finishing and Cleaning

Data sheet (PDF)

Chilled Iron Shot

Cast abrasives

Hardness: 57-64 HRC (640-800HV)
Size: von 0.045 (G020) – 2.80 mm (G240)
Shape: Round

Data sheet (PDF)

Stainless Steel Shot

Cast abrasives

Hardness: min. 30 HR C (300 HV1)
Size: von 0.05 (S 10) – 3.00 mm (S 300)
Shape: Round
Application: Deburring, Coating removal, Descaling, Cleaning and Structuring

Data sheet (PDF)

Steel Grit

Cast abrasives

Hardness: min. 46 – 52 HRC (480 – 550 HV1): Typ GP
Size: von 0.07 (G 120) – 2.80 mm (G 12)
Shape: angular
Application: Roughening, Rust removal, Coating removal, Descaling, Matt finishing, Cleaning and Sweeping

Data sheet (PDF)

Steel Shot HC

Cast abrasives

Hardness: 46 – 51 HRC (450 – 535 HV1)
Size: von 0.12 (S70) – 2.80 mm (S780)
Shape: Round
Application: Shaping, Hardening, Deburring, Rust removal, Coating removal, Descaling and Cleaning

Data sheet (PDF)

Steel Shot LC- KOTAR

Cast abrasives

Hardness: min. 40 – 50 HRC (400 – 520 HV1)
Size: von 0.12 (KOTAR 38) – 3.35 mm (KOTAR 48)
Shape: Round
Application: Deburring, Rust removal Coating removal, Descaling and Cleaning

Data sheet (PDF)

Stainless Steel Grit

Cast abrasives

Hardness: Ca. 58 HR C (660 HV1)
Size: von 0.05 (GM 10) – 3.00 mm (GM 300)
Shape: angular
Application: Roughening, Coating removal, Matt finishing, Sweeping, Descaling and Cleaning

Data sheet (PDF)

Blastex® CP

Copper cut wire shot

Hardness: min. 110 – 140 HV0.5
Size: von 0.40 – 2.40 mm
Shape: cylindrical
Application: Deburring, Descaling and Cleaning

Blastex® AL

Aluminium cut wire shot

Hardness: min. 90 – 140 HV0.5
Size: von 0.40 – 1.60 mm
Shape: cylindrical
Application: Deburring, Descaling and Cleaning

Data sheet (PDF)

Blastex® BS

Brass cut wire shot

Hardness: Depending on material grade
Size: von 0.40 – 2.40 mm
Shape: Cylindrical
Application: Deburring, Descaling and Cleaning



Blastex® BZ

Bronze cut wire shot

Hardness: Depending on material grade
Size: von 0.40 – 2.40 mm
Shape: cylindrical
Application: Deburring, Descaling and Cleaning



Blastex® ZN

Zinc cut wire shot

Hardness: min. 35 – 45 HV0.2
Size: von 0.50 – 1.60 mm
Shape: cylindrical
Application: Deburring, Descaling and Cleaning

Data sheet (PDF)

Synthetic abrasive

Non-metallic abrasives

Hardness: 3 – 4 Mohs
Size: von 0.2 – 1.60 mm
Shape: angular
Application: Deburring, Coating removal and Cleaning



Fused alumina

Non-metallic abrasives

Hardness: ca. 8 – 9 Mohs
Size: von 0.053 (F 220) – 2.00 mm (F 12)
Shape: angular
Application: Roughening, Rust removal, Coating removal, Matt finishing, Cleaning and Structuring

Data sheet (PDF)

Glass granulate

Non-metallic abrasives

Hardness: 6 – 7 Mohs
Size: von 0.08 – 1.40 mm
Shape: angular
Application: Roughening, Coating removal, Matt finishing, Cleaning



Glass beads

Non-metallic abrasives

Hardness: ca. 6 – 7 Mohs, ca. 58 HRC and ca. 645 HV
Size: von 0.004 – 0.85 mm
Shape: Round
Application: Shaping, Hardening, Deburring, Coating removal, Smoothing, Polishing, Cleaning and Structuring

Data sheet (PDF)

Ceramic beads

Non-metallic abrasives

Hardness:  ca. 7 – 7.5 Mohs, ca. 60 HRC, ca. 700 HV
Size: von 0.00 – 0.85 mm
Shape: Round
Application: Shaping, Hardening, Coating removal, Smoothing, Polishing and Cleaning

Data sheet (PDF)
